GNDM - Traverse Cutting & Profiling

GNDMR/L Series - For Shallow Grooving, Turning and Copying

Sumitomo GND External Toolholder

* Wide Range
Capable of handling various types of machining processes including grooving, traverse machining, copying, facing and boring.
* Stable Tool Life
A variety of chipbreakers improve the chip control in various applications.
* Reduced chattering and high efficiency machining
To mono-block, die steel bodies reduce vibration by approximately 30% as compared to conventional products.
* Precision edge width of polishless inserts
Sumitomo's high precision sintering technology allows a tolerance of +/-0.03mm in grooving width for 1.25 ~ 6.0mm edge widths

GNDMR - Right Hand Version
GNDML - Left Hand Version

Click Here for Sumitomo GND Series Video

Add to Favourites

Code	Product Name	Price	Stock Level
SU GNDMR2020K-1.510	GND External Holder 20mm 1.5mm Insert	$375.32 (Excl GST)	Out of Stock
SU GNDMR2020K-210	GND External Holder 20mm 2.0mm Insert	$375.32 (Excl GST)	Out of Stock
SU GNDMR2020K-312	GND External Holder 20mm 3.0mm Insert	$375.32 (Excl GST)	In Stock
SU GNDMR2020K-418	GND External Holder 20mm 4.0mm Insert	$375.32 (Excl GST)	In Stock
SU GNDMR2525M-312	GND External Holder 25mm 3.0mm Insert	$417.01 (Excl GST)	In Stock
SU GNDMR2525M-418	GND External Holder 25mm 4.0mm Insert	$417.01 (Excl GST)	In Stock
SU GNDMR2525M-518	GND External Holder 25mm 5.0mm Insert	$417.01 (Excl GST)	Out of Stock
SU GNDMR2525M-618	GND External Holder 25mm 6.0mm Insert	$417.01 (Excl GST)	Out of Stock
